Coaxial Cable KBK-2B Nrog Hluav Taws Xob Cable 2 * 0.75 Rau Sab Hauv Tsev

Coaxial Cable KBK-2B Nrog Hluav Taws Xob Cable 2 * 0.75 Rau Sab Hauv Tsev

Coaxial cable KBK-2B nrog lub zog cable 2 * 0.75 rau sab hauv tsev Daim ntawv thov l RF teeb liab kis l MATV, CATV, CCTV l Cov kab xev video l l hauv kev tshaj tawm l Satellite systems Specification l Cov Thawj Coj CU Φ0.36 ± 0.01mm l Rwb thaiv tsev SPE Φ2 .2 ± 0.2mm l Braiding Cu 96 * 0.12mm l Txheej Sab nrauv ...

Xa kev nug

Tsham tam sim no

Product Details ofCoaxial Cable KBK-2B Nrog Hluav Taws Xob Cable 2 * 0.75 Rau Sab Hauv Tsev

Thov

lRF teeb liab kis

lMATV, CATV, CCTV

lDigital video thov siv

lDrop hauv kev tshaj tawm

lSatellite tshuab

Specification

lInner Tus Kws Cuam Tshuam CU Φ0.36 ± 0.01mm

lInsulation SPE Φ2.2 ± 0.2 hli

lBraiding Cu96 * 0.12 hli

lOuter Sheath PVC Φ8.0 ± 0.2 hli

lPower Cable Cu 2 * 0.75mm²

Kev Ua Hluav Taws Xob (20 ℃)

Impedance: 75 ± 3 Ohm

Peev Xwm: 54 ± 3pF / m

Rov Qab Poob: 20dB min (5-2300MHz)

Sparker Test: 4000VAC

Kev Tshaj Tawm Ntawm Kev Hais Tawm: 85%

Cov Qauv Hluav Taws Xob (20 ℃)

Zaus (MHz)	5	10	50	100	200
Siab tshaj plaws (dB / 100m)	10.5	13.8	31.8	45.5	66.5
